GATE TITAN V2 Basic Module (Read Wired) (TTN2-BMR2)

TITAN is our flagship Electronic Trigger Unit, taking your airsoft game to the next level. Make no compromises and utilize years of experience of many thousands of users around the world, proving TITAN to be the best choice for advanced and professional players. Gain a unique tactical advantage matching your skills, thanks to the reliable MOSFET with tons of functions such as Hair Trigger, BURST Mode, Active Brake, Binary Trigger, extremely fast Trigger Response, and other essentials.

One of the advantages of TITAN V2 are the 8 optical sensors. Unlike mechanical switches prone to faults, optical sensors are much more reliable. With an additional dongle you can adjust trigger sensitivity with military precision. If you need even more control, select one of the Nova Triggers – adjustable speed triggers designed especially for TITAN V2.

What makes TITAN so special?

*5 Optical trigger sensors enabling Hair Trigger

*3 Optical gear and selector sensors

*Automatic Pre-Cocking

*Replicates trigger response just like in a real gun

*Configuration of all settings via the Bluetooth® dongle Blu-Link and GCS App for Android and iOS devices

*Configuration of all settings via USB-Link and the GCS App for Android, Windows, and macOS devices

*Sector gear sensor supporting most popular types of gears: DSG, SSG, 19-Tooth, and standard ones

*Innovative optical sensors instead of mechanical switches prone to faults

*Binary Trigger as one of the basic functions

*Premium level functionality

Programming :

Thanks to our built-in technology, you choose how to configure TITAN. Do you need a quick change in the settings on the battlefield? You can do this via the trigger. Need more functions? Choose the Tactical Programming Card. But if you prefer full control with a visual interface, connect your replica via the USB-Link or Blu-Link dongles to our GCS App.

This programming mode allows you to configure the basic functions of TITAN with the use of just the trigger and selector of your replica. During programming, the functions and options are indicated by vibrations and sounds.

The following TITAN options can be programmed via trigger:

TECH SPECS :

*Supply Voltage Range: 3.75-17 V

*Current Consumption: 24 mA

*Low Power Mode: 280 µA

*Dimensions (Length x Width x Height): 47.4 x 28.7 x 13.5  mm

*Finished Product Weight: 27.6 g

*Operating Temperature Range: min. -15°C max. + 50°C

*Relative Humidity: ≤ 80%
